Additional Reading

In-Feed

Snapshot

Nomenclature

Specifications For Text Assets

• AD TITLE: Text, <25 Characters

• TAGLINE (AD DESCRIPTION): Text, <100 Characters

• CTA: Text, <10 Characters

• ICON: Recommended Image Size is 20KB

Specifications For Image Assets

Note

Only 1 image per aspect ratio is needed, not one for every resolution. Image sizes up to 100MB are supported. However, it is strongly recommended to follow the guideline (<500KB) to minimize render losses. The lowest resolution image is recommended to maximize reach.

Technical Specifications

Field

Optional/Mandatory

Specifications

Video

Mandatory

Video Format

Linear VAST MP4 (H.264 Encoded)

Aspect Ratio

16:9

Video Dimensions

Max – 300x168

Maximum Video File Size

500 KB
We have seen 30% higher render rates with low video footprint, thereby increasing the campaign’s scale.

Video Length

6 secs – 30 secs

Video Frames

Max 23 FPS

Audio Format

MP3 or AAC Preferred Constant Bitrate - 80 Kbps Bitrate, 1 Channel, 16 KHz Sampling Rate

Companion Ad

Optional

Format

PNG, JPEG

Size

568x320, 300x250

Maximum File Size

100 KB

Companion Type

1 (Static resource only)

Note

For non-video in-feed units, please reference specs for 320x50 and 300x50 banners (slides 11 and 12).

Request

TYPE A:

  • bidrequest.imp[].instl = 0
  • bidrequest.imp[].video.placement = 4 (In-Feed)
  • bidrequest.imp[].video.maxduration = 30
  • bidrequest.imp[].video.playbackmethod = 5 or 6 (on entering viewport with sound on or off)
  • bidrequest.imp[].video.playbackend = 1 (on Video completion or when terminated by user)
  • bidrequest.imp[].video.pos =  0 (Unknown)
  • bidrequest.imp[.video.ext.experiences = [1] (denoting only landscape video support)

Inventory

Each placement can be enabled for either video only or video and static.

VAST Tag

VAST tag to contain multiple .mp4 media files having the following required attributes:

  • Delivery: progressive
  • Type: media/mp4, H.264/ AAC encoded.
  • Width: the native width of the video file, in pixels.
  • Height: the native height of the video file, in pixels.
  • Bitrate: average bitrate of the media file.
  • The VAST tag can contain a companion ad in a png/jpeg format.

Aspect Ratio

  • 16:9, maximum video dimensions: 300x168
  • Video files of any other aspect ratio will be padded with black space to fit the 16:9 video player.
  • Multiple media files (having various bitrates) matching the above spec are strongly recommended.
  • InMobi SDK picks up the best matching media file based on network connection speed and device type.

Transcoding Guidelines

  • Frame Rate: Max 23 FPS
  • Resolution: 300x168
  • Video Size: Max 500KB
  • Bitrate:
    • Video: Recommended to have one video file having a constant bitrate.
    • Audio: MP3 or AAC preferred Constant Bitrate - 80 kbps Bitrate 1 Channel, 16 kHz Sampling Rate.
